產品簡介

SX2KL-33F200E-32.768KHz,2520mm,FCD-Tech數字設備晶振,CMOS振蕩器,FCD-Tech進口晶振,荷蘭進口晶振,時鐘晶體振蕩器,有源貼片晶振,2520mm超小型晶振,32.768KHZ振蕩器,CMOS輸出晶振,SMD振蕩器,尺寸2.5x2.0mm,頻率32.768KHZ,電壓3.3V,輸出CMOS,高抗沖擊晶振,高品質晶振,低電壓晶振,低功耗晶振,便攜式設備晶振,智能穿戴晶振,測試設備晶振,無線局域網晶振.

產品詳情

SX2KL-33F200E-32.768KHz,2520mm,FCD-Tech數字設備晶振,CMOS振蕩器特點:

超小型封裝有源晶振

高抗沖擊/振動性（半導體工藝）

擴展可用的溫度范圍，非常快速地啟動

定制頻率0.5Hz至500MHz

應用：便攜式電子產品.

SX2KL-33F200E-32.768KHz,2520mm,FCD-Tech數字設備晶振,CMOS振蕩器 參數表

Item	Speci?cation 32.768 kHz (please consult factory for custom make frequency 0.5 Hz - 500 MHz)
Frequency Range	32.768 kHz (please consult factory for custom make frequency 0.5 Hz - 500 MHz)
Output Logic	CMOS
Overall Frequency Stability *	± 200 ppm typ . ~ ± 500 ppm max
Operating Temperature Range	-20 ~ +70°C
Supply Voltage Vdd	+3.3V ±5%
Supply CurrentIdd	15 µA max
Output Level	VOH ≥ 0.9 VddVOL ≤ 0.1 Vdd
Output Load	15 pF
Symmetry	45 / 55 %
Rise Time / Fall Time	20 ns max
Tri-state function	pin #1 = high or open pin #1 = low	pin #3 ==>oscillation pin #3 ==>high impedance
Start-up Time	1 ms max.
Shock resistance	20000GS
Packing Unit
Soldering Condition
